@ky28059/react-free-transform
A flexible, CSS matrix()-based library for free-transform of arbitrary HTML elements in React.
1npm i @ky28059/react-free-transformA simple example using the base <FreeTransformContainer /> component:
A more complex example with custom transform controls, using the useFreeTransform() hook:
For basic use cases, use the <FreeTransformContainer /> component. The FreeTransformContainer renders a wrapper div that registers the transform controls on itself. The current transformation, as well as some callback functions, are exposed to the component's children via a render callback.
1import { FreeTransformContainer } from '@ky28059/react-free-transform';
2
3export default function Example() {
4 return (
5 <FreeTransformContainer className="...">
6 {({ transform }) => (
7 // Render your wrapper children here
8 <img
9 src="..."
10 className="..."
11 style={{ transform }}
12 draggable={false}
13 />
14 )}
15 </FreeTransformContainer>
16 )
17}Component API:
| Prop | Type | Value |
|---|---|---|
| className | string? | An optional className to apply to the wrapper div. |
| children | (s: FreeTransformState) => ReactNode | A render function that returns the container's children. |
where the render callback is passed an object with properties
| Prop | Type | Value |
|---|---|---|
| transform | string | The CSS property value of the current transform. |
| zoom | (p: number) => void | A callback that zooms the container by the given scale (e.g. zoom(0.3) roughly dilates the transform by 130%). To zoom out, pass a negative value (e.g. zoom(-0.1)). |
| reset | () => void | A callback that resets the current transformation. |
For more advanced use cases, use the useFreeTransform() hook directly.
1import { useFreeTransform } from '@ky28059/react-free-transform';
2
3export default function Example() {
4 const { register, transform, zoom, reset } = useFreeTransform();
5
6 return (
7 <div>
8 <div
9 // For the controls to work, it's recommended that your container has the following styles:
10 className="flex items-center justify-center overflow-hidden touch-none ..."
11 ref={register}
12 >
13 <img
14 src="..."
15 className="..."
16 style={{ transform }}
17 draggable={false}
18 />
19 </div>
20
21 <button className="..." onClick={() => zoom(0.1)}>
22 +
23 </button>
24
25 <button className="..." onClick={() => zoom(-0.1)}>
26 -
27 </button>
28
29 <button className="..." onClick={reset}>
30 Reset transformation
31 </button>
32 </div>
33 )
34}The hook returns an object of
| Prop | Type | Value |
|---|---|---|
| register | (c: HTMLElement | null) => void | A callback that registers the given HTMLElement as a transform wrapper. When registering a JSX element, you can pass this callback as a ref. |
| transform | string | The CSS property value of the current transform. |
| zoom | (p: number) => void | A callback that zooms the container by the given scale. |
| reset | () => void | A callback that resets the current transformation. |
